NRF24L01P-R RF Transceiver ICs

The NRF24L01P-R is a single-chip 2.4GHz transceiver with an embedded baseband protocol engine (Enhanced ShockBurst™), suitable for ultra-low-power wireless applications. The nRF24L01+ is designed for operation in the worldwide ISM frequency band at 2.400 – 2.4835GHz.

The Nordic nRF24L01+ is a highly integrated, ultra low power (ULP) 2Mbps RF transceiver IC for the 2.4GHz ISM (Industrial, Scientific and Medical) band. With peak RX/TX currents lower than 14mA, a sub μA power down mode, advanced power management, and a 1.9 to 3.6V supply range, the nRF24L01+ provides a true ULP solution enabling months to years of battery life from coin cell or AA/AAA batteries. The Enhanced ShockBurst™ hardware protocol accelerator offloads time critical protocol functions from the application microcontroller enabling the implementation of advanced and robust wireless connectivity with low cost 3rd-party microcontrollers.

The nRF24L01+ integrates a complete 2.4GHz RF transceiver, RF synthesizer, and baseband logic including the Enhanced ShockBurst™ hardware protocol accelerator supporting a high-speed SPI interface for the application controller. No external loop filter, resonators, or VCO varactor diodes are required, only a low cost ±60ppm crystal, matching circuitry, and antenna.

The nRF24L01+ is available in a compact 20-pin 4 x 4mm QFN package.


Low cost, single-chip 2.4GHz GFSK RF transceiver IC
Worldwide license-free 2.4GHz ISM band operation
250kbps, 1Mbps and 2Mbps on-air data-rate options
Enhanced ShockBurst™ hardware protocol accelerator
Ultra low power consumption – months to years of battery lifetime
Drop-in compatible with the Nordic nRF24L01 previous generation Nordic RF transceiver IC
Fully on-air compatible with all Nordic nRF24L Series, as well as nRF24E and nRF240 Series

NRF24L01P Manufacturer
Nordic Semiconductor is a fabless semiconductor company specializing in short-range wireless and low-power cellular IoT. Nordic pioneered ultra-low-power wireless and helped develop Bluetooth Low Energy, a widely-adopted wireless technology. The company’s award-winning Bluetooth LE solutions have made it the market leader, and are complemented by ANT+, Thread, and Zigbee products. Nordic’s reputation is built on the supply of leading-edge wireless technologies and development tools that shield designers from RF complexity. This approach extends to Nordic’s latest technology, cellular IoT. Launched in 2018 after four years of development, this NB-IoT and LTE-M solution leverages cellular infrastructure to extend the IoT.


NRF24L01P is basically a wireless transceiver, which is used to send and receive data by using radio waves. It is a single-chip transceiver module. It uses the SPI protocol for transmitting data. Its data transmission speed is up to 2Mbps. NRF24L01P is normally used in industrial devices and projects for data transmission. If you want to purchase it and search for the best electronic components supplier, you can contact UCC INDU GmbH for the best quality.
